Bourns SRF9045A AEC-Q200 High Current Common Mode Choke provides 700Ω typical common mode (CM) impedance at 100MHz to suppress electromagnetic interference (EMI). This compact choke measures 9mm x 7mm x 4.5mm. Other features include 7.5µH inductance and a 5A current rating. The SRF9045A utilizes a sector-wound configuration winding for normal common mode impedance and increased differential mode impedance at high frequencies. The series offers common mode filtering and differential mode filtering in a single choke configuration. Bourns SRF9045A AEC-Q200 High Current Common Mode Choke is ideal for use in DC/DC converters, switch-mode power supplies, and power line noise suppression and noise filtering.
Shielded construction, low radiation
RoHS compliant and halogen-free
EMI suppression and noise filtering in power lines
Switch-mode power supplies
700Ω @ 100MHz typical CM impedance
9mm x 7mm x 4.5mm dimensions
Bourns SRF High Current Power Inductors
Designed for automotive applications, including information/entertainment systems.
