Alpha Wire EcoFlex® PUR Flex Cable provides more than 8 million flex cycles in tough application conditions while saving space and reducing weight. These cables are up to 40% smaller and 44% lighter than traditional flex cables while resisting oil, solvents, UV radiation, and abrasion. Alpha Wire EcoFlex PUR cables remain flexible at low temperatures and are available in a variety of conductor sizes and counts with shielded and unshielded versions.
More than 8 million flex life cycles
Resists oil, solvents, UV radiation, and abrasion
No halogens, phthalates, or heavy metals
Two to 36 conductors
Unshielded or braid shielding
28AWG to 10AWG
-50°C to +90°C (static)
-40°C to +80°C (dynamic)
• UL AWM 21959 (90°C, 600VRMS) • UL Oil Res I • UL sunlight resistant • CSA AWM I/II A/B FT2 • IEC60228 Conductors, Class 6 • EU Low Voltage Directive 2006/95/EC • IEC 60332-1 and 60332-2 flame behaviors • IEC60754-2 acid gas generation
Alpha Wire EcoFlex® Cables
Rated for 1 million flex cycles, 100% recyclable, and no halogens, phthalates, or heavy metals.
